SEL-710 Motor Protection Relay—Thermal Model Elements and Settings

During this recorded technical presentation SEL presenters Derrick Haas and Krithika Bhuvaneshwaran discuss the thermal element in the SEL-710 Motor Protection Relay. The thermal element is used to provide locked rotor, running overload, and negative-sequence current unbalance protection.

During the webinar, you will:

• Learn about the first-order thermal model.
• Understand the different methods to set the thermal element.
• Develop settings using the rating method and check coordination.

You can use the knowledge gained from this webinar to set the thermal element and understand how the motor is protected.
